Tutorial / Assembling

Before Start

The BOM (bill of materials) list is available at http://gainer.sourceforge.net/gainer_v1-0-0_bom.pdf

If you purchased all components, please check to make sure before starting to assemble.

  • The GAINER I/O module PCB
  • PSoC CY8C29466: 1
  • IC Socket: 1
  • Ceranmic Capacitor 0.1uF (104): 3
  • Ceranmic Capacitor 0.01uF (103): 1
  • Electroci Capacitor 10uF: 1
  • Tactile Switch: 1
  • LED (white): 1
  • LED (red): 1
  • Resistor 330ohm: 2
  • USB connector
  • Machine pin: 2
